Fuel Capacity: 14.8 gal
Turning Radius: 24.9 ft
Engine: 4-stroke, DOHC, 4-valve, in-line 4-cylinder, liquid-cooled
Displacement: 999cc
Cargo Bed Dimensions (LxWxH): 14.6 x 33.1 x 9.1 in
Maximum Horsepower: 250.0 hp¹ @ 9,000 rpm
Cargo Bed Load Capacity: 300 lb
Maximum Torque: 146.3 lb-ft @ 8,800 rpm
Payload Capacity: 1,076 lb
Bore x Stroke: 73.4 x 59.0mm
Seating Capacity: 4-person (2 row), bucket seats with 4-point seatbelts
Compression Ratio: 7.8:1
Lighting: All-LED lighting
Fuel System: DFI® with (4) 40mm throttle bodies with dual injection; Kawasaki Supercharger
DETAILS
Ignition: TCBI with electronic advance
Frame: Ladder type, tubular steel
Starting System: Electric
Overall Length: 159.4 in
Transmission: Automatic CVT with centrifugal clutch (H,L,N,R)
Overall Width: 74.0 in
Final Drive: Selectable 2WD/4WD with locking front differential, shaft
Overall Height: 73.8 in / 78.5 in (with antenna)
Engine Braking: Yes
Estimated Dry Weight: 2,361.6 lb** / 2,363.8 lb** CA Model
Curb Weight: 2,496.1 lb* / 2,498.3 lb* CA Model
Wheelbase: 126.0 in
CAPABILITY
Front Suspension / Wheel Travel: Double wishbone, FOX 3.0 Live Valve Internal Bypass shocks with piggyback reservoir, KECS-controlled compression damping, and manually adjustable spring preload/23.2 in
Rear Suspension / Wheel Travel: 4-link trailing-arm rear suspension, FOX 3.0 Live Valve Internal Bypass shocks with piggyback reservoir, KECS-controlled compression damping, and manually adjustable spring preload/24.0 in
Front Tires: Maxxis® Carnivore Plus 33 x 10.00R16
Rear Tires: Maxxis® Carnivore Plus 33 x 10.00R16
Instruments: Digital speedometer, tachometer, fuel gauge, gear indicator (L, H, N, R), Driving Mode (2WD/4WD/4WD+Diff Lock), Power Mode (Full/Mid/Low), Suspension Mode (Soft/Normal/Firm), Camera Mode, Economical Riding Indicator, connected indicator, clock, odometer, dual trip meters, total time, trip time, average speed, engine temperature, intake air temperature, battery voltage, boost pressure, CTV temperature, seatbelt warning lamp, maintenance reminder, oil warning lamp, engine check lamp, engine temperature warning lamp, neutral indicator, reverse indicator, headlight high-beam indicator, parking indicator lamp, battery warning lamp, EPS warning lamp, and CVT belt warning lamp
Steering: Electric Power Steering (EPS) / rack-and-pinion
Additional Features: 10-in Garmin Tread® with (4) 6.5-in speakers, 7-in Full-color TFT Instrumentation with Smartphone Connectivity via RIDEOLOGY THE APP POWERSPORTS, Plastic roof, Steel skid-plates w/ drain holes, ERGO-FIT®, 2 DC outlets, 2 USB ports, 8 cup holders, Additional storage
Front Brakes: 270mm dual hydraulic discs with 3-piston calipers
Rear Brakes: 270mm dual hydraulic discs with 2-piston calipers
Ground Clearance: 16.5 in (max) / 16.1 in (std)
Color Choices: Lime Green
